Mercury Pure Sinewave Inverter 4KVA/48V

Overview for Mercury 4KVA/48V Pure Sine Wave Inverter with UPS Functionality

Mercury 4kva 1nverter Pure Sine Wave with  UPS functionality is a generation ahead of the entire category. That’s because our break through chip embedded sine wave’ technology delivers the same current as you get from your mains.  The distinguishing features of this Mercury 4KVA inverter Pure Sine Wave are:

Specification

Model: MI 4250
System Rating (VA/W): 2800W
INPUT
Nominal Input Battery Voltage 48V: 48V
Voltage Range: 180 VAC – 265VAC ± 5 VAC (UPS Mode), 90 VAC – 280 VAC ± 10 VAC (NOR Mode)
BATTERY CHARGING
Grid Charging Current: 12A, 18A (2 Modes)
MODES
UPS / Normal: Via Switch (Back Side)
Charging Mode (FC/NC): Via Switch (Back Side)
Battery Selection NA: Via Switch (Back Side)
OUTPUT
Wave Form Type: Pure Sine Wave
Output Voltage: 200VAC ± 10%
Output Frequency: 50Hz ±.5 Hz
Overload Protection Provided at: >100% with auto reset
Low Battery Protection Provided a:  ≤10.4V (per Battery) with auto reset
Short Circuit Protection Provided at: ≥300% with manual reset
Over Temperature Protection Provided at:  ≥85° C
CHANGE OVER TIME
UPS Mode: ≤12 milliseconds
Normal Mode: ≤50 milliseconds
BATTERY
Boost Voltage: 14.4 VDC ± 0.2VDC TT Mode: 14.6 VDC ± 0.2 VDC
FT Mode: 14.2 VDC ± 0.2 VDC
Float Voltage: 13.5 VDC ± 0.2VDC TT Mode: 13.8 VDC ± 0.2 VDC
FT Mode: 13.5 VDC ± 0.2 VDC
Low Battery Cut: 10.4 VDC ± 0.2 VDC
Battery Type: 12V (100Ah to 200Ah)
ENVIRONMENT
Forced Cooling: Through Cooling Fan
Humidity: 0-90% Non-Condensing
Operating & Storage Temperature: 0-45° C
DISPLAY
Display Type: LCD
LED: NA
LCD Status: Mains Voltage, Output(Load) Voltage, Battery Voltage, Charging Current,

Discharging Current, Load Percentage,Battery Charging/ Charged, Charging Mode, Battery Mode
Protection: Mains Hi / Low, Mains Fuse / MCB Trip, Over Temp, Short Circuit, Battery Low Trip, Overload Trip
PACKAGING
Dimension(LxWxH) Inch: 13×10.5×16 13.8×11.8×21.6
